SGWM-PB Precision injector

The Slootsmid SGWM-PB precision fertilizer spreader is specially designed for the application of natural fertilizer substitutes such as mineral concentrate, ammonium sulfate, wash water, and low doses of liquid manure in grass and cereal fields. The unique design of the machine with six distributors, interconnected, ensures a perfect distribution across the entire working width. At all outlets, the pressure remains exactly the same at all times, allowing for a consistent application rate of 4,000 to 30,000 liters per hectare. Hydraulic valves and ISO-bus control enable the closure of sections based on GPS.

SGWM-PB Precision injector
SGWM-PB Precision injector
SGWM-PB Precision injector
SGWM-PB Precision injector
SGWM-PB Precision injector

Product description

  • Unique machine suitable for low doses of liquid manure, digestate, wash water, and mineral concentrate
  • Working width of 12 meters, equipped with 6 cutting mini distributors, ensuring 100% distribution
  • Consistent delivery of the liquid, applied directly into the soil, not spotwise or on leaves, which could cause burning
  • Delivery rate ranging from 4,000 to 30,000 liters per hectare at a speed of 12 km/h.
  • Hard-faced discs 300 mm, 180 mm centre-to-centre
  • Elements follow track and ground contours
  • Optionally fully ISO-bus and GPS controlled

Specifications

SpecificationsSGWM-PB 1200
Working width (m)11,88
Weight (kg)3,300
Transport width (m)2,90
Transport height (m)3,70

Thoughtful construction

The Slootsmid SGWM precision fertilizer spreaders feature a unique and robust construction combined with a relatively low weight. The frames are fully galvanized, and the outlets are made of stainless steel, ensuring a long lifespan with low maintenance costs.

Precision dosing

The SGWM-PB spreader from Slootsmid Mesttechniek can dose from 4,000 to 30,000 liters per hectare at a speed of up to 12 km/h. This makes it particularly suitable for the application of natural fertilizer substitutes and low doses of liquid manure. The spreader is available in a working width of 12 meters and can be optionally equipped with section control, automatic lubrication, and a tow hitch.

Optimal distribution

The precision fertilizer spreaders are equipped with Slootsmid mini-exact distributors, designed in such a way that there is exactly the same pressure on all outlets. With the placement of multiple distributors, there is a continuous supply to each element. This eliminates V-shaped buildups on the headlands.

Video

Sgwm Reintjes 03

Downloads

Frequently asked questions

What is the difference between the SGWM and SGWM-PB precision injectors?

The SGWM is a reliable precision injector with excellent distribution and ground contour following. The SGWM-PB is the more advanced version with six Slootsmid Exact distributors, section control, ISOBUS control and adjustable down pressure per element. The PB version offers working widths up to 15 m (instead of 13 m), providing additional capacity and flexibility.

Which applications and conditions are best suited for the SGWM-PB?

The SGWM-PB is designed for precision on larger fields. Like the SGWM, it is ideal for applying organic fertilisers and low slurry rates on grassland and cereal crops. With section control, ISOBUS operation and larger working widths, it delivers maximum precision and efficiency.

What is the weight?

SGWM-PB 1200 (12.00 m): 3,300 kg

SGWM-PB Precision injector

SGWM-PB Precision injector

The Slootsmid SGWM-PB precision fertilizer spreader is specially designed for the application of natural fertilizer substitutes such as mineral concentrate, ammonium sulfate ...

Why choose Slootsmid?

Slootsmid has acquired a leading position in the market as an innovator in the field of manure processing, as it has been developing and producing injectors in its own unique way and according to its own philosophy for over 40 years. The end user and the fertilization result have always been at the forefront. All products are extensively tested in practice and optimized in consultation with the end user. This has resulted in a complete range of high-quality injectors for various application areas, all with outstanding fertilization results. Characteristics of Slootsmid’s injectors include:

  • Excellent fertilization results
  • Minimal damage to sod and soil
  • Low own weight
  • Long lifespan and low maintenance costs
